Digital I/O kort

PCI 10 kanals 16 bits tæller kort og 8 kanale I/O

Supports a 32-bit 5 V PCI bus
On-board four 82C54 programmable timer/counter chips
10-CH independent 16-bit down counters
1-CH 32-bit cascaded timer
Four programmable clock sources for each timer/counter
Programmable de-bounce filter for external clock & external interrupt inputs
8-CH TTL DI & 8-CH TTL DO

Supports a 32-bit 5 V PCI Express bus
24/48/96-CH digital TTL/DTL inputs/outputs
Emulates 2 industry standard 8255 PPI (mode 0)
Support Windows 7/8 X64/X86 and Windows 2008 R2
Output port status read back
On board 8254 timer/counter chip
Programmable interrupt source
12V and 5V power supply to OPTO-22 (Direct interface with OPTO-22)

PCI Express-kort med 96 TTL I/O-kanaler og 3 tellere

X1 PCI Express-grensesnitt
96-CH digitale TTL/DTL innganger/utganger
Emulerer 4/2/1 industristandard 8255 PPI (modus 0)
Direkte grensesnitt med OPTO-22-kompatible I/O-moduler
Utgangsportstatus leses tilbake
Ombord 8254 timer/tellerbrikke
Programmerbar avbruddskilde
Støtte Windows 7/8 X64/X86 og Windows 2008 R2

med tilstandsdetektor på alle 32 innganger
Optoisulerte innganger - 2.5kv - Common Ramme
Logikk: Lav 0-3,2VDC, Høy: 3.5 - 24VDC

16 optoisolerede indgange, fælles stel (minus) og 16 optoisolerede udgange,

Supports a 32-bit 5 V PCI bus
16-CH isolated digital inputs
16-CH isolated digital outputs - Open-Collector
5000 VRMS optical isolation
Sink current up to 500 mA on each isolated output

Supports a 32-bit 5 V PCI bus
64-CH isolated digital inputs
2500 VRMS optical isolation
Sink current up to 500 mA on each isolated output

16 optoisolerte inngange, felles stel (minus) og 16 optoisolerte utgange,

Støtter en 32-bits 5 V PCIe Express-buss - LAVPROFILKORT
16-CH isolerte digitale innganger
16-CH isolerte digitale utganger - Open-Collector
5000 VRMS optisk isolasjon
Senkstrøm opp til 500 mA på hver isolert utgang

8 af de digitale udgange kan trække op til 500mA pr. kanal

32-CH optical-isolated digital input
32-CH optical-isolated digital output
Isolation Voltage: 3750 Vrms (Using external power)
Card ID: Jumper setting for multi-board identification
Open Collector: 8-channel - 500mA, Current Sinking, NPN
Open Collector: 24-channel - 100mA, Current Sinking, NPN

Relæerne holder deres stilling, selv om strømmen til kortet afbrydes

Supports a 32-bit 3.3 V or 5 V PCI bus
16-CH latching SPDT relay outputs
Power saving on relay actuation
Output status unchanged when power-off
On-board LED indicators for relay status
16-CH isolated DI
Change-of-status (COS) interrupt
Board ID

Slave kort til REL8OPT8PCI

Supports a 32-bit 5 V PCI bus
8-CH relay outputs on PCI-7250
8-CH isolated DI
On-board LED indicators for relay status
On-board relay driving circuits
Relay output stats read back
On-board low-pass filtering for DI

Antal af ind- og udgange kan udvides til 32

Supports a 32-bit 5 V PCI bus
8-CH relay outputs
8-CH isolated DI
On-board LED indicators for relay status
On-board relay driving circuits
Relay output stats read back
On-board low-pass filtering for DI
Extendable up to 32-CH relay outputs

PCI kort med 8 relæer og 8 optoisolerede indgange

8-CH high power relay outputs (5A @ 250VAC or 30VDC)
8-CH isolated digital inputs with AC-filter
1-CH emergency shutdown input
Pluggable connector for high current input
Supports universal 32-bit 3.3V and 5V PCI bus
Initial state and safety state setting by DIP switches
Built-in watchdog timer

Support a 32-bit 3.3 V or 5 V PCI bus
32-CH TTL digital inputs and 32-CH TTL digital outputs
Up to 12 MB/s transfer rate
Bus mastering DMA for both digital inputs and outputs
On-board programmable timer pacer clock
Supports handshaking digital I/O transfer mode
Multiple programmable interrupt sources
Compact, low-profile PCI size PCB

Support a 32-bit 3.3 V or 5 V PCI bus (LPCI-7200S)
32-CH TTL digital inputs and 32-CH TTL digital outputs
Up to 12 MB/s transfer rate
Bus mastering DMA for both digital inputs and outputs
On-board programmable timer pacer clock
Supports handshaking digital I/O transfer mode
Multiple programmable interrupt sources
Compact, low-profile PCI size PCB

16 optoisolerede indgange, fælles stel (minus) og 16 optoisolerede udgange,

Supports a 32-bit 5 V PCI bus - LOW PROFILE CARD
16-CH isolated digital inputs
16-CH isolated digital outputs - Open-Collector
5000 VRMS optical isolation
Sink current up to 500 mA on each isolated output

Universal PCI interface til +5 V and +3.3 V PCI bus.
Op til 24 digitale I/O kanaler
Programmerbare I/O porte
DIO response time 0.77 μs (1.3 MHz max.)
WIN Vista,98/NT/2000 and XP/2003 32-bit version OS

10 x digitale input (0 - 50VDC)
8 x relæ output (skifterelæ, 0,25A @ 230VAC, 2A @ 30VDC)
Forsynes via USB
Alle Digitale input kan bruges som 32-bit tæller
8kV ESD beskyttelse
Udvidet temperatur -25 til +75°C
Isolation: 3000 VDC
Watchdog - hardware og software
Benytter ikke driver - SDK udviklingsværktøj findes

Støtter en PCI Express x1, Plug and Play (PCIe-7256)
16-CH låsende SPDT-reléutganger
Strømsparing ved relémanøvring
Utgangsstatus uendret når strømmen er slått av - LED-indikatorer for reléstatus
16-CH isolert DI
Bytte av status (COS) avbryt
Styrings ID

4-Port 10/100 / 1000T 802.3at PCI Express
PoE + (120 W)
Intel I350 Controller til 4 x RJ45
Dimensjoner: 169 x 121 x 18 mm | Vekt 251 g
Driftstemperatur temperatur~~POS=HEADCOMP: -10 ~ 60 C

2-Port 10/100 / 1000T 802.3at PCI Express
PoE + (60W)
Intel I350AM2 Controller
2 x RJ45
Dimensjoner: 169 x 121 x 19 mm
Vekt 161 g
Driftstemperatur temperatur: -10 ~ 60 C
