HDMI-forlenger 4K opp til 60 meter over RJ45 cat 5e/6/7, Sett med sender og mottaker.

Sender Inkludert 4K / HD Video og lyd over CAT6A / 7 Kabel opp til 100 meter
HDBaset Communication Protocol (5 i 1)
HDBaset Supporter: Audio Video, Drift, Ethernet, USB, Strøm
Kan drives fra HDBaset med PSE
PSE er utstyr som sender poe ut på RJ45 Port
Strøm fra mini-USB uten PSE-tilkoblet
Kart HDMI-kabel, eliminerer behovet for ekstra kabler
Oppløsning Opp for UHD (3840 x 2160), Deep Color og HD Audio Formater
4K @ 60Hz 4: 2: 0
4K @ 30Hz 4: 4: 4
HDCP Kompatibel og Blu-Ray Klar
Plug-and-Play Ingen programvareinstallasjon
Krever best kvalitet kabel! Ingen støtte hvis ikke kabelen er fra Danbit

Simple way to transfer HDMI signal using CAT 6/6e cable.
Features:
Long range transmission:up to 50m/165ft over a single CAT6 cable;
Video resolution:Up to1920x1080P@60Hz,3D;
Audio sampling rate:32kHz, 44.1kHz and 48kHz ;
Audio Format:DTS-HD/Dolby-true HD/LPCM7.1/DTS/DSD ;
Uncompressed mode:ZERO Delay,No loss
Male to male:one TX to one RX applicataion;
Copy EDID:It is extended display identification data , Press the button 3seconds, the TX will copy the signal data, like auto-match.They remember the EDID information if you plug them off the power adapter and them turn them back again;
Video standard:compliance with HDMI 1.3 and HDCP 1.2 standard;
Built-in automatic adjustment system:make the image smooth, clear and stable;
Built-in ESD protection system：make transmission much safer. Perfect hdmi extension adapter for large homes, factories, construction sites, data control centers etc;plug and play
Simple to install, plug and play

Specifications:
HDMI Version: HDMI 1.3
HDCP Version: HDCP 1.2
Resolution: 1920x1080P@60Hz resolution, compatible with 3D

Connection instructions:
HDMI cable: HDMI 1.3 cable within 10 ft.(at 1080P@60Hz)
Ethernet cable: Cat6/7 within 50m/165ft, Cat5e within 40m/130ft.
Ethernet cable RJ45 wiring sequence: T568B (white orange, orange, white green, blue, white blue, green, white brown, brown)

Remind:
1）Directly connect your signal source and monitor before connecting HDMI Extender, and check the signal status.
2）Power the TX to run the devices by connecting your computer, laptop, USB adapter with the included USB power cable (no adapter).

4K HDMI Extender over IP
HDMI 1.4 / HDCP 1.4
Opptil 120 meter (punkt-til-poeng)
4k @ 30 Hz
2 x USB-A 2,0 (HID-emulering)
En-til-en eller en-til-mange
Max 32 stk. RX kan kobles til 1 TX (via Ethernet Switch)
Remote-IR fra TX til RX
Plug and Play
Power Tilførsel: 5V 1A (2 forsyninger)
Dimensjoner: 107 x 105 x 27 mm
Driftstemperatur: -15 - + 55 ° C
Vekt: TX 499G, RX 494G
Oppkjøp: K-USB4AM-AM-FE for å koble USB-en port til PC

HDMI BOOSTER HD 1080p
HDMI-signal over enkelt CAT 5e/6-kabel
Oppløsning 1920 x 1080 @60Hz
POC: Power Over-kabel. Senderen driver mottakeren
HDMI 1.3/HDCP 1.2
Forsyningsspenning: 5VDC
