Managed switch, 8 porter 100/1000Mbit RJ45, PoE+ (36W), 2 x 100Mbit / 1Gbit SFP, 2 x 10Gbit SFP
8 x 10/100 / 1000BASE-T RJ45 Auto-MDI / MDIX-porter
2 x 1000BASE-SX / LX / BX SFP-grensesnitt
8 POE-injeksjonsporter med 802.3ay /
PoE Standard 802.3at
60GB ikke-blokkering
32Mbits Databuffer
IEEE 802.3X pause ramme for dupleks
IP30 aluminium
Din skinne og veggmontering
Alarm relé 1A, 24V DC
2 x Digital utgang (DI)
2 x Digital utgang (DO) 24v DC, 100mA max
Dimensjoner: 72 x 107 x 152mm
Vekt: 1684g
Forsyning: 48-56 V DC
