8 x BNC-komposittvideoinnganger for 1 x BNC-utgang, trykknappvalg og fjernkontroll

Komposittvideobryter
8 Input BNC Hier til 1 Output BNC He
Støtter lavere strømforbruk ved full belastning under 500 mA
AC / DC-adapter - 12 VDC, 300 mA
Videoforvrengning: 0 .5 dB
fjernkontroll IR
For veggmontering
175 x 81 x 25 mm

SW8BNC-1COMP
2 822  NOK
Eksklusive MVA
Antall
På vei inn

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

compact composite video/BNC distribution amplifier which supports 8 inputs and 1 output. It is ideal for distributing video signals from security cameras, DVDs, video game consoles, satellite receivers, cable/satellite boxes, and other such devices, to up to 8 screens. The composite splitter is designed to support high-resolution videos for up to 200' (60.96 m) output cable runs.

Annen
Menu & IR Remote controller
Dimensioner
17.5 x 8.1 x 2.5 cm
Forsyning
12 VDC @300 to 1000 mA
Input
8x BNC female port
Isolation
60 dB, 6.5 dB Gain between any input and output
LED
Control by front pushbuttons with LCD readout
Montering
Metal: Wall mountable ear panels attached
Opsætning
Easy to install and simple to operate
Output
1x BNC female port
Tilbehør
Remote control
Trådløs
IR Frequency 38 KHz
Vekt
0.49 kg
