Embedded PC med miniOS7, med 80186, 80MHz CPU, 2G GSM GPRS med SD-kort, data logging

Embedded PC LAN og 2G (GPRS) inkl. Minios7
80186, 80 MHz CPU
1 x 10/100 Base-TX Ethernet
1 x RS-232
1 x RS-485
512 KB Flash / 16 KB EEPROM / MicroSD / 256 MB NAND Flash Disk
64 Bit
for DIN Rail Montering
Supply 12-48VDC, 2.5W
Driftstemperatur: -25 til + 75 °

M485-PC-ETH-G-I
2 017  NOK
Eksklusive MVA
Antall
Fysisk på lager

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Embedded PC LAN og 2G (GPRS) inkl. Minios7 med 80186, 80 MHz CPU. 512 KB Flash / 16 KB EEPROM / MicroSD / 256 MB Nand Flash Disk

CPU
80186, 80 MHz
Annen
I/O Expansion Bus Yes (for one XW-Board only)
Dimensioner
91 mm x 123 mm x 52 mm
Driftstemperatur
-25 ~ +75°C
Forsyning
12-48VDC, 2,5W
Hukommelse
SRAM 512 KB Flash 512 KB microSD Expansion Yes, up to 32GB micro SD cards are supported NAND Flash Disk - 256 MB
LED
5-digit 7-segment LED display for (D) versions
OS SUPPORT
MiniOS7 (DOS-like embedded operating system)
Porte
EthernetRJ-45 x 1, 10/100 Base-TX, COM 1 RS-232 (TxD, RxD, RTS, CTS, GND), COM 2 RS-485 (Data+, Data-).
Watchdog
Yes (0.8 second)
