I/O module 6 x Digital Input, 6 x Relay output via Ethernet for industrial control tasks, PoE

6 x Digital input, 6 x Relay output via Ethernet for industrial control applications. 1 x RJ45 PoE

6 x Digital Inputs - Wet (active at DC in)
6 x Power relay outputs - 24VDC / 250VAC / 5A
Protocol: Modbus TCP / UDP
1 x RJ45 Ethernet interface with PoE in
I / O Pair-function - the input is mirrored to the second output
Digital inputs with counter - max 500Hz
the minimum pulse width: 1 ms
Screw terminal
Supply voltage: PoE or 10 - 30VDC / 3watt

3,195.23 NOK
Excl. VAT
Quantity
Physically in stock
LÆG I KURV
Product number ETHIO6I6PR-P-I
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

Forsyning 10 - 30 VDC, 2,5 W via klemrække eller PoE
Indgang 6 stk. digitale Logisk 0: 0 - 4 VDC, Logisk 1: 10 - 50 VDC
Netværk 10/100 Mbit m/RJ45-stik
Protokol Modbus/TCP, TCP/IP og UDP
Tæller Indgange kan virke som 32 bit tæller, maks. frekvens 500 Hz
Udgange 6 stk. relæudgange: AC: 250 V og 5 A eller DC: 30 V og 5 A. Skiftetider Lukke/åben er 7ms / 3 ms

ETHIO6I6PR-P-I giver 6 digitale kontaktkanaler til våd kontakt og 6 elektromekaniske relæer fra form A. Den har optisk isolering til 3000 VDC af forbigående beskyttelse mod overspænding og har ikke kanal-til-kanal-isolering. Hver inputkanal kan bruges som en 32-bit tæller. Tændingsværdien og den sikre værdi for relæet er programmerbare.

Bemærk: Når der er tilsluttet induktive belastninger til relæerne, kan der opstå en stor modelektromotorisk kraft, når relæet aktiveres på grund af den energi, der er lagret i lasten. Disse flyback-spændinger kan beskadige relækontakterne og forkorte relæets levetid kraftigt. Begræns disse flyback-spændinger ved din induktive belastning ved at installere en flyback-diode til jævnstrømsbelastninger eller en metaloxidvaristor til vekselstrømsbelastninger.
