Serial Port Converter with PoE
2x 3-wire RS-232 Port
Supports Baud Rate Up to 115200 bps
Parity Options: None, Odd, Even, Mark, Space
Data Bit Configurations: 5, 6, 7, 8
Stop Bits Options: 1, 2
Operating Temperature: -25 ~ +75 °C
Humidity: 10 ~ 90% RH, non-condensing
32-bit ARM CPU
Dimensions: 52 mm x 27 mm x 95 mm
Power input: 12-48VDC
Power Consumption: 0.07 A @ 24 VDC
Plastic Casing with DIN-Rail Mounting
| Serial | 2 x 3-wire RS-232 115200 bps Max. |
|---|---|
| Ethernet | 10/100 Base-TX, 8-pin RJ-45 x 1 (Auto-negotiating, Auto-MDI/MDIX, LED indicator) PoE (IEEE 802.3af, Class 1) |
| Montering | Din-rail mounting |
| Drifttemperatur | -25 ~ +75 °C |
| Dimensioner | 52 mm x 27 mm x 95 mm (W x L x H) |
