CPU Intel® 14th/13th/12th Core™ LGA1700 Socket (Max. 35W)
RAM 1 x 262-pin DDR5 SO-DIMM 4800/5600MHz SDRAM MAX.32GB
Intel® H610E, Integrated Intel® UHD Graphics 730/770
1 x 2.5GbE ports 2 x GbE ports, (1 x Intel® i226LM, 1 x Intel® i219LM,1 x Intel® i210AT)
Watchdog Timer
TPM: dTPM 2.0
2xCOM ( 1x RS232, 1x RS232/422/485)
8x USB ( 2 x USB-A 3.2 Gen2 (10Gbps) 2 x USB-A 3.2 Gen1 (5Gbps) 2 x USB-A 2.0 2 x Internal USB-A 2.0)
1 x M.2 E-key 2230 slot (PCIe 3.0 x1 + USB2.0 + CNVi)
1 x mPCIe (PCIe 3.0 x1 + USB 2.0, Full size) w/ 1 x nano SIM card slot
1 x DisplayPort 1.4 (DP++), up to 4096x2304@60Hz
1 x VGA, up to 1920x1200@60Hz
1 x M.2 M-key 2242/2280 slot (PCIe 4.0 x4 + SATA)
Wall-mount (standard), DIN-rail (optional w/ CTOS bracket)
-20 ~ 60°C, ambient w/ air flow
CE, FCC Class A
Dimensions (W x D x H) 55 x 164 x 210mm
DC 12~24V via 2-pin terminal block, max. 80W
OS SUpport: Windows 10 / Windows 11 / Ubuntu
| CPU | Intel® Core™ i3-12th Gen<br>Intel® Core™ i3-13th Gen<br>Intel® Core™ i3-14th Gen<br>Intel® Core™ i5-12th Gen<br>Intel® Core™ i5-13th Gen<br>Intel® Core™ i5-14th Gen<br>Intel® Core™ i9-12th Gen<br>Intel® Core™ i9-13th Gen<br>Intel® Core™ i9-14th Gen |
|---|---|
| Memory Type | DDR5 |
| Max. Memory Capacity | 32 |
| Graphics | Integrated Intel® UHD Graphics 730/770 |
| Expansion | 1 x mPCIE<br>1 x nano SIM card slot |
| Power Input | DC 12~24V |
| Max. Power Consumption | 170W |
| USB | 4 x USB-A 3.2<br>2 x USB-A 2.0 |
| Serial | 1x RS232<br>1 x RS232/422/485 |
| LAN | 1x 2.5Gb LAN<br>2x 1Gb LAN |
| Operating Temp. | -20 ~ 50°C |
| Storage Temp. | -30 ~ 70°C |
| Operating Humidity | 10-95% @ 60°C (non-condensing) |
| Vibration | 5~500Hz 3 Grms |
| Shock | 10G peak acceleration (11 m sec. duration), operation<br>30G peak acceleration (11 m sec. duration), nonoperation<br>According to IEC 68-2-27 |
| Weight | 2.5KG |
| Dimensions | 55 x 164 x 210mm |
| Certification | CE/FCC Class A |
| Antal Video Udgange | 2 |
| Antal LAN Porte | 3 |
| Antal USB | 6 |
| Antal Serial | 2 |
