X-KEYS - Mini contact with closing contact. Used for USB contact boxes. Cord with 3.5mm jack connector.

USB Matrix card for 128 digital inputs
128 contact points as 8 x 16 grid
8 x 16 matrix for external switch keys.
USB cable included

USB adapter for max. 3 push buttons:
Splitter cable K-USB-KEY3 must be purchased separately.
With a 3-splitter cable, the USB-KEY3 can be programmed for 3 different HID commands
Additional push buttons (foot pedal or similar) with end switch, 3.5mm jack, common frame
Program the HID command into the adapter for each push button
Button setup is stored in the USB adapter

8 pieces. 22mm buttons in a robust safety orange box
Buttons with make-contact (NO)
Key-force activation 770g
USB switch box with DB15HD plug
For harsh environments, IP65, water -, oil and chemical resistant
Cable 5meter. USB A connector on the cable from the switch box
Dimensions: 320 x 57 x 48 mm
Weight: 567g
High Force buttons in protected groove to prevent accidental
Hanger bracket for attachment of cable
Designed for low voltage - below 32VDC / 1A (no high voltage)
Perfect for industrial processes
Macro programmed in X-KEYS USB box
macros in USB KEY ROBUST8 Plug and Play

2 pcs. 22mm buttons in a robust security orange box
push-buttons with connectors
Pressure power for activation 770g
X-Keys USB contact boxes - See our selection
for harsh environments , IP 65, water, oil and chemical resistant
2.9 meters Robust cable for 3.5mm connector
target: 133 x 57 x 48 mm
Weight: 567g
High Force buttons in Protected recess to prevent accidental activation
bracket for attachment of cable
design for low voltage - under 32VDC / 1A (not high voltage)
Perfect for start / stop (Macro programmed in X-KEYS USB box) For example: Control and display menus in industrial screens
Next and back buttons in computer controlled automation systems

USB Switch interface
6 input ports for push buttons with 3.5mm jack connector.
3.5mm Jack is stereo and can handle 2 push buttons
if 12 push buttons, then with optional splitter cable
For USB Port
Mountering Flanges
Any button pressure can trigger USB HID command
Software for button macro programming
setup lies in the device

Round contact in red - End contact
push button Switch - Over 20 million Press
accessories for USB-Key Contact box series
can be fixed - Holes in base
3.6 meter wire with 3.5mm Mono-Jack
Dim: diam 69 x Height 20 mm
Material: plastic

USB foot pedal with software - can execute HID macros via the USB port
Each switch is programmed for its own macro.
With the manufacturer's PC software select key functions
The macros are stored in the foot pedal
The foot pedal can be moved to another PC and the macros are included
Is independent of operating system.

The pedal is rear hinged

Round contact in green - end contact
push button Switch - Over 20 million Press
accessories for USB-Key Contact boxes series
Can be fixed - Holes in base
3.6 meter cord with 3.5mm Mono-Jack
Goal: diam 69 x Height 20 mm
Material: plastic
